1″ dome tweeter with surface housing and in-line high pass filterHigh-performance Mylar dome tweeter25 mm / 1″ voice coilMylar domeNeodymium motorIncl. 12 dB/oct high pass filterFerrofluid cooled1 pair / packageFlush and surface mount housing included(GZTH 25-28B)
Model
High-performance tweeter with Mylar dome
Diameter
25 mm / 0.98″
Power Handling (RMS/max.)
70 / 100 Watts
Impedance
4 Ohms
Efficiency
84 dB
Frequency Response
3000 Hz – 20 kHz
Crossover Frequency
5500 Hz (Crossover high pass frequency)
Voice Coil
25 mm / 1″
Dome
Mylar
Mounting Ø
48 mm / 1.89″
Mounting Depth
16 mm / 0.63″
