SounDigital 800.5 EVO 6 - 4 Ohm

It′s not just about audio. It′s sensation, technology and emotion. IT′S EVO6. This isn′t just another amplifier, it′s a leap in the evolution of car audio. It redefines amplifier design. Every detail has been redesigned for excellence in audio quality, making your musical perception much more immersive. Introducing the new 800.5 EVO6. With the help of AI we have achieved a miniaturization never seen before, these are the smallest amplifiers in the world, breaking power density records. High efficiency that fits anywhere. Join us on a journey into the future. Power @ 4Ω: 4 x 100W RMS Power @ 8Ω: 4 x 66W RMS SUBWOOFER: 4Ω: 1 x 400W Bridge Power @ 8Ω: 2 X 200W RMS SUBWOOFER: 8Ω: N/A Frequency Response (-3dB): 80Hz ~ 25kHz SUBWOOFER: 5Hz ~ 80Hz Low Pass Filter (12dB/octave): 80Hz High Pass Filter (12dB/octave): 80Hz Operating Voltage: 9V ~ 16V SNR: 103.88dB SUBWOOFER: 102dB Input Sensitivity (RCA): 0.2V ~ 2V Current Draw (music): 39A Current Draw (max.): 78.7A Total Efficiency: 80% Damping Factor (@100Hz nominal impedance): 200 Power Cable: 10mm² (7 AWG) Speaker Cable: 1.5mm² (15 AWG) / 2.5mm² (13 AWG) Recommended Fuse (music): 40A Recommended Battery (minimum): 60Ah Width: 6.01″ / 15,7 cm Lenght: 4.52″ / 11,7 cm Height: 2.07″ / 5,5 cm Weight: 0.74 kg / 1.63 lb Älä kytke vahvistinta alle nimelliskuorman! Do not run your amp under rated impedance!.
