SounDigital 12000.1 EVOX 1ohm

The EVO X Line brings the latest technology in a compact design with the highest quality components. From a pioneering technology, SounDigital brought to car audio amplifiers something that hadn′t been explored yet. The thermal coupling through the RTGP system.The exclusive RTGP system (Thermal Recovery for Power Generation) assures SounDigital products with both higher thermal efficiency and robustness with higher stability.

Compatible with SD-RLC Remote level control.

- Power @ 12.6V @ 4Ω: 1 X 5227 WRMS
- Power @ 12.6V @ 2Ω: 1 X 7920 WRMS
- Power @ 12.6V @ 1Ω: 1 X 12000 WRMS
- Power @ 14.4V @ 4Ω: 1 X 5828 WRMS
- Power @ 14.4V @ 2Ω: 1 X 8831 WRMS
- Power @ 14.4V @ 1Ω: 1 x 13380 WRMS
- Operating Voltage: 8V – 16V
- Current Draw (Music): 627 A
- Current Draw (Max): 1253 A
- Recommended Fuse (Music): 675 A
- Total Efficiency: 76%
- Damping Factor: 200
- Frequency Response (-3dB): 5Hz – 500Hz
- SNR: 76dB
- Crossover HPF: 5Hz – 30Hz
- Crossover LPF: 50Hz – 500Hz
- THD + N (10% Rated Power): 0.1%
- Product Dimensions: 20.8 x 8.8 x 2.8 in

Älä kytke vahvistinta alle nimelliskuorman!

Do not run your amp under rated impedance!.
