AMPIRE KV-DOBLO

Reversing camera for FIAT DOBLO 2 / OPEL Combo Fastening screws accessible from the front Image reproduction mirrored Auxiliary lines: switched on at the factory (can be switched off by separating a cable loop) Image sensor: 1/3 ″CMOS PC3089 Resolution 720x480 pixels Viewing angle 150 ° diagonally Viewing angle 120 ° horizontally Image format: NTSC 580 lines resolution IP68 waterproof Minimum lighting 0.1 lux Operating voltage: 9-16 volts DC Power consumption: max. 150mA Operating temperature: -20 ° to 70 ° C Cable length: 10m + 1.5m on the camera E approval E9-10R-05.1652 CE approval EN 55022: 2010 EN 61000-3-2: 2006 + A1: 2009 + A2: 2009 EN61000-3-3: 2008 EN 55024: 2010 FCC approval ANSI C63.4-2003 Installation note: The camera is not suitable for continuous operation or monitoring. It must not be operated with an ignition (K15), as this could damage the camera through overheating.
